Data Path FX4
The Datapath Fx4 offers the perfect solution for staging and televised video walls. Delivering four SDI outputs and the ability to loop multiple units together, even the largest, most complex video wall installations are possible.
 4K @ 60 fps input
 Multple input choices
 Contact Sales
 Four SDI outputs
 Rotates, crops and scales

Data Path FX4

  • Click Here for a PDF download of the DataPath FX4 Manual.

  • Size: 316mm (l) x 172mm (w) x 42mm (h)
    Weight: 1.86kg


    OPERATING TEMPERATURE
    0 oC to 35 oC / 32 oF to 96 oF


    POWER REQUIREMENTS
    IEC switched and fused mains connector 100-240V,
    50/60Hz / 35W


    VIDEO INPUT CONNECTIONS
    1 x DisplayPort1.2 (2160p60 or equivalent up to 616MP/s)
    2 x HDMI1.4 (2160p60 (4:2:0), 2160p30 or equivalent up to 297MP/s)


    VIDEO OUTPUT CONNECTIONS
    HDMI version: 4 x HDMI1.3 (1080p60, 1200p60 or equivalent up to 165MP/s)*
    DisplayPort version: 4 x DP1.1 (1080p60,1200p60 or equivalent up to 165MP/s)*
    * Outputs within 165MP/s but taller/wider than 2048 require testing
    Loop-through (both versions): DisplayPort1.2 (locked to selected video input resolution)


    INPUT SURFACE
    8K x 8K maximum


    GENLOCK INPUT
    Analog black-burst on dedicated BNC connector. Any video input (HDMI1, HDMI2, DisplayPort)


    CONTROL INTERFACES
    Dual 100Base-T Ethernet ports with inbuilt managed switch. USB 2.0 Type B connector



    FIRMWARE SUPPORT
    Updates supported via USB and Ethernet connection


    STORAGE
    -20 °C to 70 °C / -4 oF to 158 oF


    RELATIVE HUMIDITY
    5%-90% non-condensing
